导出Excel
| Model Number | Case Style | RF/LO Freq. Low (MHz) | RF/LO Freq. Hi (MHz) | I&Q Freq. (MHz) Min., DC to … | I&Q Freq. (MHz) Max., DC to … | Conv. Loss (dB), Typ. | Conv. Loss (dB), (σ) | Conv. Loss (dB), Max. | Carrier Rejection (dBc), Typ. | Carrier Rejection (dBc), Max. | Sideband Rejection (dBc) Typ. | Sideband Rejection (dBc) Min. | Harmonic Suppression (dBc), 3XI/Q Typ. | Harmonic Suppression (dBc), 3XI/Q Max. | Harmonic Suppression (dBc), 5XI/Q Typ. | Harmonic Suppression (dBc), 5XI/Q Max. | LTCC Construction |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| JCIQ-176M+ | BG291 | 104 | 176 | DC | 5 | 5.6 | 0.1 | 7 | 35 | 30 | 35 | 30 | 45 | 35 | 65 | 50 | - |
| JCIQ-88M+ | BG291 | 52 | 88 | DC | 5 | 5.6 | 0.1 | 7 | 40 | 32 | 35 | 30 | 45 | 35 | 65 | 50 | - |
